About the Zoll X Series Monitor / Defibrillator
The Zoll X Series delivers real-time CPR feedback that actually shows compression depth and rate values during resuscitation, not just after the fact. Its See-Thru CPR algorithm filters out compression artifacts so you can monitor the underlying rhythm without stopping chest compressions.
The split-screen capability lets you view multiple waveforms simultaneously while acquiring 12-lead ECGs that transmit directly to receiving facilities. Worth noting: the CPR Dashboard includes a timer that tracks compression intervals, giving your team objective data on resuscitation quality in real time.
At under 12 pounds, it’s lighter than most monitor/defibrillators while packing WiFi, Bluetooth, and cellular connectivity. The 6.5-inch color display stays readable in bright transport environments.
Key Features
- Real-time CPR depth and rate feedback with compression timer
- See-Thru CPR algorithm reduces compression artifacts during monitoring
- Split-screen display for simultaneous waveform viewing
- 12-lead ECG acquisition with wireless transmission capability
- Integrated WiFi, Bluetooth, and cellular connectivity
- Weighs less than 12 pounds for easy transport
- Large 6.5-inch bright color LCD display
Specifications for Zoll X Series Monitor / Defibrillator
General
- Weight: 11.7 lb (5.3 kg) with battery and paper
- Dimensions: 8.9 x 10.4 x 7.9 in (22.6 x 26.4 x 20.1 cm)
- Operating Temperature: 0 – 50°C
- Humidity: 15 – 95% RH (non-condensing)
- Altitude: -170 m to 4572 m
Monitor / Display
- Size: 6.5 in (16.56 cm) diagonal
- Type: Color LCD, 640 x 480 pixels, 800 MCD
- Sweep Speed: 25 mm/sec or 50 mm/sec (user selectable)
- Lead Selections: Paddles (Pads), I, II, III, AVR, AVL, AVF, V1-6
Inputs
- Input: 3-lead, 5-lead, or 12-lead patient cable, paddles, or multifunction electrodes
Defibrillator
- Waveform: Rectilinear Biphasic
- Energy Selections: 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 15, 20, 30, 50, 70, 85, 100, 120, 150, 200 joules
- Energy Display: Display indicates selected and delivered energy
- Charge Time: Less than 7 seconds with a new, fully charged battery
- Charge Controls: Front panel and on apex paddle
- Pads/Paddles: Hands-free pads and external adult and pediatric paddles; adult paddles slide off to expose pediatric paddles
- Synchronized Mode: Synchronizes defibrillator pulse to patient’s R wave; ‘SYNC’ message displayed on monitor and markers shown on both monitor and recorded ECG
Monitoring Capabilities
- ECG: Multi-lead monitoring and 12-lead acquisition
- SpO2: Masimo SET SpO2
- CO/Met: Masimo rainbow SET SpCO, Masimo rainbow SET SpMet
- NIBP: Noninvasive blood pressure
- EtCO2: Microstream etCO2
- Respiration: Impedance Pneumography
- Invasive Pressure: Supported
- Temperature: TEMP
