About the G3 Acuity Wireless DR Panels
Description not Found
Specifications for G3 Acuity Wireless DR Panels
G3 Acuity 1717
- Model: 17 x 17 Tethered
- Detector Type: Direct Deposition Csl
- Weight: 9.5 lbs
- Active Area: 430 x 430 mm
- Pixel Pitch: 140 μm
- Resolution: 3072 x 3072
- A/D Conversion: 16-Bit
- Input Voltage: Max Voltage of 57VDC @ 1A
- Communication: Gigabit Ethernet (LAN Cable)
- X-Ray I/F: Lossless AED/AWC. Sync Trigger
- Model: 17 x 17 Wireless
- Detector Type: Direct Deposition Csl
- Weight: 7.6 lbs
- Active Area: 430 x 430 mm
- Pixel Pitch: 140 μm
- Resolution: 3072 x 3072
- A/D Conversion: 16-Bit
- Input Voltage: 7.4VDC @ 3A
- Communication: Gigabit Ethernet (LAN Cable)
- X-Ray I/F: Lossless AED/AWC. Sync Trigger
G3 Acuity 1417
- Model: 14x 17 Wireless
- Detector Type: Direct Deposition Csl
- Weight: 6.5 lbs
- Active Area: 358 x 430 mm
- Pixel Pitch: 140 μm
- Resolution: 2560 x 3072
- A/D Conversion: 16-Bit
- Input Voltage: 7.4VDC @ 3A
- Communication: Gigabit Ethernet (LAN Cable)
- X-Ray I/F: Lossless AED/AWC. Sync Trigger
G3 Acuity 1417
- Model: 10x 12 Wireless
- Detector Type: Direct Deposition Csl
- Weight: 4.1 lbs
- Active Area: 233.47 x 291.84 mm
- Pixel Pitch: 76 μm
- Resolution: 3072 x 3849
- A/D Conversion: 16-Bit
- Input Voltage: 7.4VDC @ 3A
- Communication: Gigabit Ethernet/IEEE 802.11n (5 GHz)
- X-Ray I/F: Lossless AED
