Certified Refurbished

Philips Heartstart FR3 Defibrillator

The Philips HeartStart FR3 cuts response time with pre-connected SMART Pads III that eliminate the fumbling for electrode placement during cardiac arrests.

New List Price $1.00

Your Savings

DRE Price $1.00

Select Condition

Clear

Refurbished

Add to quote

Our equipment specialists are here to help you with your questions.

Hours: Monday – Friday 8AM – 5PM ET

The Philips HeartStart FR3 cuts response time with pre-connected SMART Pads III that eliminate the fumbling for electrode placement during cardiac arrests. Unlike basic AEDs that just shock, this unit provides real-time CPR feedback specific to each patient’s chest compression depth and rate.

The high-resolution color display shows actual ECG rhythms alongside text prompts, giving clinical staff the visual confirmation they need during resuscitation. Quick Shock technology delivers therapy in under 8 seconds from rhythm analysis, and bilingual voice prompts adapt to your facility’s staff needs. Worth noting: the optional Infant/Child key automatically adjusts energy output for pediatric patients without swapping pad sets.

The unit’s compact form factor fits standard crash cart mounts, while stainless steel components handle the daily abuse of emergency transport and decontamination protocols.

Key Features

Pre-connected SMART Pads III for immediate deployment
Patient-specific CPR guidance with compression feedback
Quick Shock technology minimizes CPR interruptions
High-resolution color LCD displays ECG and prompts
Configurable bilingual voice and text guidance
Optional Infant/Child key for pediatric energy reduction

Materials

Components: Stainless Steel

Pads: SMART Pads III (disposable, can be preconnected)
Optional Accessories: Infant/Child Key, FR3 data card, Training battery and training pads (optional)

Waveform

Type: SMART Biphasic Truncated Exponential
Adult Nominal Peak Current: 32A (150J into a 50 ohm load)
Pediatric Nominal Peak Current: 19A (50J into a 50 ohm load) with optional Infant/Child Key

Display and Indicators

ECG Display: High-resolution color LCD, 320 x 240 pixels (2.8″ x 2.1″)
Indicators: Beeper, voice prompts, tones and chirps, audio speaker, ready light, shock button

Battery

Primary Battery: 12 VDC, 4.7 Ah lithium manganese dioxide
Primary Battery Capacity: Typically 300 shocks or 12 hours monitoring after No Shock Advised configuration; 7.5 hours when configured for CPR after NSA
Standby Life: 3 years minimum (battery installed)
Training Battery: 10.8 V, 4.5 Ah Li-ion (optional)

Physical

Size: 2.7″ high x 5.3″ wide x 8.7″ deep
Weight: 3 lbs 8 oz (with FR3 primary battery installed)

Environmental and Durability

Sealing: Meets IEC529 Class IP55 with battery installed
Temperature: Operating/Standby: 32°–122°F
Altitude: Meets IEC 60601-1:5.3 (equivalent to 0 to 15,000 feet)
Shock/Drop: Meets MIL-STD-810F 516.5, Procedure IV (one-meter drop in standby)
Vibration: Meets MIL-STD-810F 514.5 C-17

Connectivity and Data

Wireless: Bluetooth 2.0 Class II transceiver
Data Storage: FR3 data card stores a minimum of 8 hours of ECG, event, and optional voice recording

Patient Analysis and Performance

ECG Analysis: Lead II (anterior-anterior adult pads placement), evaluates pad impedance, ECG rhythm, signal quality, artifact and pacemaker
SMART CPR: Evaluates VF characteristics to determine therapy sequence (shock first or CPR first)
Quick Shock: Typically arms in <8 seconds from end of "Stop CPR" prompt
Sensitivity/Specificity: Meets AAMI DF80 requirements and AHA recommendations for adult defibrillation

Intended Use

Settings: Designed for use by emergency technicians and professional responders in field and clinical environments
