Abbott Plum XL Infusion Pump
The Abbott Plum XL runs dual infusion lines from a single pump head, letting you handle primary and secondary infusions without swapping tubing or managing.
Quality Management
Facility & Processes
Biomedical Technicians
About the Abbott Plum XL Infusion Pump
The Abbott Plum XL runs dual infusion lines from a single pump head, letting you handle primary and secondary infusions without swapping tubing or managing multiple devices. You get delivery rates from 1 to 999 mL/hr in precise 1 mL increments, plus automatic piggyback capability that returns to primary infusion when secondary doses complete.
The pump accepts both parenteral and enteral fluids through standard containers including fullfill bags, partfill containers, syringes, and vials. Worth noting: the keep-vein-open function automatically drops to 1 mL/hr at dose completion, maintaining line patency without manual intervention. The sealed lead-acid battery provides reliable portable operation across care settings from home health to ICU.
Key Features
- Dual-line volumetric infusion from single pump unit
- 1-999 mL/hr delivery range in 1 mL increments
- Automatic piggyback and KVO functionality
- Compatible with parenteral and enteral fluids
- Accepts standard fullfill, partfill, syringe, and vial containers
- Rechargeable battery for portable operation
Specifications for Abbott Plum XL Infusion Pump
Capacity
- Delivery Rate Range: Primary, Secondary Mode: 1 to 999 mL/hr (in 1 mL increments)
- Dose Limit Range: 1 to 9999 mL (in 1 mL increments)
- KVO: 1 mL/hr
Weight
- Weight (without batteries and PBlade): 375 g
- Weight (with battery): Approximately 7.75 lbs
Dimensions
- External Dimensions: Approximately 8.25H × 7.5W × 8.75D inches (including pole clamp)
Materials
- Casing: High-impact plastic
- Components: Plastic; Stainless Steel
Power Requirements
- AC Input: 100-130 VAC, 50 to 60 Hz, less than 35 W
- Power Cord: Hospital-grade AC cord, 10 feet long, with transparent plug
- Fuses: 0.5 A, 250 V, slow-blow
Battery
- Type: Sealed lead-acid rechargeable 8 V battery, internal to infusion system
- Field Service: Battery accessible for ease of field replacement with color-coded leads and polarized connector
- Battery Operation: Fully charged new battery provides eight hours of operation at 125 mL/hr; full recharge ~16 hours; recharge in OFF/CHARGE ~8 hours
Occlusion
- Occlusion Range: 10 psig (+5, -2 psig)
Family/Type
- Family/Type: blade
Illumination
- Illumination: Conventional; Fiber Optic
Intended Use
- Settings: Home care to critical care, hospital and related clinical environments
