About the DRE InView HD Video Laryngoscope, Disposable Blades
The InView HD puts a 2-megapixel camera directly on disposable blades, giving you clear visualization without the preheating delays that slow down difficult airway cases. The anti-fog technology means you’re ready immediately, while the 66° field angle captures more of what you need to see during intubation.
Built-in recording captures every procedure to 8GB internal storage, which is worth noting for training reviews and quality assurance documentation. The footage transfers easily via micro USB, so your team can review techniques or challenging cases without additional equipment. You’ll get about 200 minutes of working time per charge.
The 3.5-inch display rotates 180° and adjusts up and down, so you won’t strain your neck during longer procedures. Bottom line: it’s lightweight enough for extended use but sturdy enough for OR demands.
Key Features
- Anti-fog 2.0 megapixel blade camera, no preheating required
- 3.5-inch rotating LCD display with 180° rotation
- Internal 8GB recording with micro USB file transfer
- 200-minute rechargeable lithium battery life
- Lightweight, ergonomic handheld design
- 66° camera field angle for enhanced visualization
Specifications for DRE InView HD Video Laryngoscope, Disposable Blades
Display
- Size: 3.5 in
- Type: LCD
- Resolution: 640 x 480 (RGB)
- Aspect Ratio: 4:3
- Video Refresh Rate: 30 FPS
Illumination
- Type: LED
Camera
- Resolution: 2.0M Pixels
- Field Angle: 66°
- Illuminance: ≥ 800 lux
Battery
- Type: Rechargeable Lithium Battery
- Voltage: 3.7 V
- Capacity: 3200 mAh
- Long Working Time: ≥ 200 min
- Charging Times: More than 300 cycles
- Charging Time: Less than 8 hr
Power / Charging
- Charging Port: Micro USB
- Input: 100 – 250 V, 50 Hz
- Output: 5 V, 1000 mA
Output / Data
- Internal Memory: 8 GB SD
- Output: File storage and transfer via Micro USB
Weight
- Weight: ≤ 350 g
Environment
- Storage Temperature: -10°C to +45°C
- Storage Humidity: ≤ 93%
- Storage Atmospheric Pressure: 500 hPa to 1060 hPa
- Working Temperature: 5°C to +40°C
- Working Humidity: 30% to 85%
- Working Atmospheric Pressure: 700 hPa to 1060 hPa
Contents
- Blade Sizes: 0, 1, 2, 3, 4
Materials
- Blade Materials: Plastic; Stainless Steel
