Penlon Sigma Delta Anesthetic Vaporizer – Isoflurane

The Penlon Sigma Delta maintains consistent isoflurane delivery even when fresh gas flows drop below 1 L/min, unlike older vaporizers that struggle with.

New List Price $1.00
Your Savings
DRE Price $1.00

Our equipment specialists are here to help you with your questions.

Hours: Monday – Friday 8AM – 5PM ET

The Penlon Sigma Delta maintains consistent isoflurane delivery even when fresh gas flows drop below 1 L/min, unlike older vaporizers that struggle with accuracy at minimal flow anesthesia. This stability matters when you’re trying to reduce agent consumption while maintaining precise anesthetic depth.

Worth noting: the ten-year service interval cuts your biomedical maintenance schedule significantly compared to vaporizers requiring annual preventive work. You’ll spend less time coordinating service windows and more time keeping ORs operational.

At 4.8 kg, it’s lighter than most competing units, and the choice between key-fill and pour-fill models lets you match your department’s safety protocols. Multiple back-bar mounting options work with most anesthesia workstation configurations.

Key Features

  • Consistent performance at low flows (0.2-15 L/min operating range)
  • Ten-year service interval reduces maintenance downtime
  • 4.8 kg weight for easier handling during installation
  • Available in key-fill or pour-fill configurations
  • Multiple back-bar mounting options for workstation compatibility

Capacity

  • Volume at Max Mark: 250 mL nominal
  • Volume at Min Mark: 35 ±0 mL
  • Residual After Draining: Approximately 60 ±0 mL retained by the wick

Performance

  • Flow Range: Operating flow range 0.2 to 15 litres/min
  • Temperature Range: Operating temperature range 15° to 35°C (58° to 95°F)

Weight

  • Weight: 4.8 kg approx.

Sizes

  • Cagemount Dimensions: 133 mm wide × 158 mm deep × 219 mm high
  • Selectatec Compatible Dimensions: 120 mm wide × 190 mm deep × 242 mm high
  • Drager Plug-In Compatible Dimensions: 100 mm wide × 190 mm deep × 242 mm high

Compatibility

  • Mounting Options: Selectatec® (with interlock), Drager Plug-In®, North American Drager, Cagemount

Materials

  • Components: Plastic
