Certified Refurbished

Hill-Rom CareAssist Hospital Bed

The Hill-Rom CareAssist cuts patient repositioning time in half with its Shearless Pivot mechanism and auto-contour features that work together automatically.

New List Price $1.00
Your Savings
DRE Price $1.00

Our equipment specialists are here to help you with your questions.

Hours: Monday – Friday 8AM – 5PM ET

The Hill-Rom CareAssist cuts patient repositioning time in half with its Shearless Pivot mechanism and auto-contour features that work together automatically. Unlike standard hospital beds that require manual adjustment for each position change, the CareAssist moves patients smoothly without friction or skin shearing.

The integrated scale system weighs patients without transfers, eliminating the workflow disruption of moving patients to separate scales. The optional Bed Exit System reduces false alarms by 60% compared to basic pressure pad systems. Point-of-care controls put bed functions within arm’s reach during patient care.

Worth noting: the instant CPR release doesn’t just drop the patient flat. The dampened descent lowers them gently while giving you immediate access. The built-in extender adds 4 inches when you need it, and the dining chair position locks securely for safe patient meals.

Key Features

  • Shearless Pivot mechanism with auto-contour reduces repositioning needs
  • Optional integrated scale (0-400 lb range, 1% accuracy) eliminates patient transfers
  • One-button Dining Chair position with secure locking
  • Instant CPR release with dampened descent
  • Point-of-care controls minimize caregiver steps
  • Four dual-locking casters with two-direction locking
  • Built-in bed extender increases sleep surface length
  • Optional Bed Exit System minimizes false alarms
  • Stowable patient pendant works in any side rail
  • Raised headboard facilitates caregiver ergonomics

Capacity

  • Weight Limit: 400 lb (181.4 kg)
  • Scale Operating Range: 0 to 400 lb (0 to 181 kg)
  • Scale Accuracy: 1% (optional)

Sizes

  • Frame Width: 39.74 in (100.95 cm)
  • Frame Length (with Head and Foot Board) – Normal: 90.04 in (228.71 cm)
  • Frame Length (with Head and Foot Board) – Extended: 94.04 in (238.86 cm)
  • Sleep Surface Width: 36 in (91.44 cm)
  • Sleep Surface Length – Normal: 80 in (203.2 cm)
  • Sleep Surface Length – Extended: 84 in (213.36 cm)

Clearance

  • Bed Clearance (Under Frame): 5 in (12.7 cm)
  • Low Position (Floor to Deck): 15.75 in (40 cm)
  • High Position (Floor to Deck): 32.24 in (81.9 cm)

Motion and Angles

  • Head Elevation: 68° (maximum)
  • Trendelenburg / Reverse Trendelenburg: 16° (maximum)

Mobility

  • Caster Size: 6 in (15 cm)
  • Casters: Four dual-locking casters

Contents

  • Built-in Bed Extender: Yes
  • Patient Pendant: Stowable in side rail

Materials

  • Components: Stainless Steel

Other

  • Alerts: Audible alert if brakes are released while bed is plugged in
  • Backup Operation: Standard back-up feature allows operation without being plugged in during transport
