DRE Infantia NB500 Incubator

Physical Weight & Dimensions

• Height: 53.31 inches (135.4 cm)
• Width: 40.31 inches (102.4 cm)
• Depth: 27.17 inches (69 cm)
• Weight: Approx. 218.92 lbs (99.3 Kg)

Temperature Control

• Air Control Range: Normal 73.4 ~ 98.6°F; Override 98.78 ~ 102.2°F
• Air Measurement Range: 68 ~ 113°F ±32.9°F
• Skin Control Range: Normal 95 ~ 99.5°F; Override 99.68 ~ 102.2°F
• Skin Measurement Range: 77 ~ 113°F ±32.54°F

Humidity

• Control Range: 30 ~ 95%
• Measurement Range: 15 ~ 99% ±5% RH (non-condensing)
• Control System: Steam (boiling at 212°F)
• Water Box Capacity: 1,000 ml (autoclavable)

Function

• Control: Microprocessor controlled with double safety feature
• Trend Recording: 9 ~ 72 hours (weighing scale 9 days); selectable 2, 4, 8, 12, 24 hour trends
• Alarms: 27 event visual & sound alarms; stop alarm options 4, 5, 15 minutes
• Warm-up Time: Silent mode 60 min; Normal mode 45 min; Fast mode 30 min
• Power Outage Alarm Duration: 30 minutes
• Additional Functions: Record/display infant name & birth date; Power on self-test

Performance & Environment

• Noise Level: Silent mode <45 dB; Normal mode <55 dB; Fast mode <66 dB
• Air Filter Particle Size: 0.3 micron
• Air Filter Efficiency: 99.8%
• Airflow: Double wall with air curtain

Contents

• Standard Accessories: IV Pole, tray, drawer
• Built-in: X-ray tray, LED examination light inside hood

Illumination

• Display: 7″ TFT color LCD

Compatibility (Optional Accessories)

• Height Lift Adjustment: Optional
• Scale: Optional
• Masimo SpO2: Optional
• External Patient Monitor: Optional

Intended Use

• Applications: Neonatal care for infants and newborns (NICU and related settings)
