DRE Compass 101 Microscope

The Compass 101 delivers sharp three-dimensional visualization for ENT procedures with a parfocal optical system that keeps your entire field in focus as.

New List Price $1.00
Your Savings
DRE Price $1.00

Our equipment specialists are here to help you with your questions.

Hours: Monday – Friday 8AM – 5PM ET

The Compass 101 delivers sharp three-dimensional visualization for ENT procedures with a parfocal optical system that keeps your entire field in focus as you change magnification. Unlike basic surgical microscopes that require constant refocusing, this setup maintains clarity across its 3-step magnification range.

Built-in green and yellow filters enhance tissue contrast during microsurgery, while 10W LED illumination provides consistent brightness without the heat buildup of halogen systems. The short version: you get 20,000 hours of reliable lighting that won’t fade mid-procedure.

The two-part arm design gives you full positioning flexibility, and the five-star base keeps everything stable during delicate work. Worth noting, the 1500mm arm reach lets you position the optics exactly where you need them without fighting the stand.

Key Features

  • 3-step parfocal magnification system maintains focus throughout zoom range
  • Built-in green and yellow color filters for enhanced tissue contrast
  • 10W LED illumination with 20,000-hour lifespan
  • Two-part articulating arm with 1500mm maximum reach
  • Five-star stability base for secure positioning

Optics

  • Objective Lens: 200/250mm standard; 300/400mm optional
  • Total Magnification: 2.4X – 12X
  • Magnification Steps: 0.6X, 1X, 1.6X
  • Fine Focusing Range: 10mm

Illumination

  • Type: 10W LED
  • Objective Illumination: 50,000 LUX
  • LED Lifespan: 20,000 hours

Dimensions

  • Column Height: 1200mm (47.24 in) max
  • Arm Length: 1500mm (59 in) max
  • Arm Height Range: 600-1550mm (23.62-61.02 in)

Power

  • Power Supply Voltage: 90V/60HZ – 250V/50HZ

Materials

  • Components: Stainless Steel

Intended Use

  • Settings: Operating Room
