Midmark Ritter 630 Barrier-Free Power Procedures Table

The Midmark Ritter 630 drops to just 19 inches for barrier-free access, eliminating transfer challenges for wheelchair-bound patients and those with.

New List Price $1.00
Your Savings
DRE Price $1.00

Our equipment specialists are here to help you with your questions.

Hours: Monday – Friday 8AM – 5PM ET

The Midmark Ritter 630 drops to just 19 inches for barrier-free access, eliminating transfer challenges for wheelchair-bound patients and those with mobility limitations. Unlike fixed-height tables that require lifting or awkward positioning, this power table adjusts from 19 to 40 inches while maintaining full tilt and positioning control.

The Premium Comfort System seat cut-out uses elastomeric material that flexes with patient movement during longer procedures. Worth noting: the Auto-Return function brings the table back to your preferred starting position with one touch, and QuickChair mode transitions from flat to seated position automatically.

Hand and foot controls keep adjustments within reach whether you’re seated or standing. Optional 350° rotation lets you reposition the entire table without asking patients to move, and programmable memory stores four custom positions for different procedure types.

Key Features

  • Power height adjustment from 19″ to 40″ for barrier-free access
  • Premium Comfort System seat cut-out with flexible elastomeric material
  • Auto-Return and QuickChair functions for one-touch positioning
  • Optional programmability for four custom position presets
  • Optional 350° rotation with foot pedal control
  • Optional heated upholstery and hospital-grade outlets

Capacity

  • Patient Load Rating: 450 lb. (204 kg)

Sizes

  • Height: Minimum 19″ (48.3 cm); Maximum 40″ (101.6 cm)
  • Patient Support Surface Length: Flat position: 72″ (182.9 cm)
  • Patient Support Surface Length: Flat position with headrest extended: 83″ (210.8 cm)

Sizes

  • Upholstery Width – Headrest: 12″ (30.5 cm)
  • Upholstery Width – Back Support: 24 – 26″ (61 – 66 cm)
  • Upholstery Width – Seat: 28″ (71.1 cm)
  • Upholstery Width – Foot Support: 18″ (45.7 cm)

Motion Ranges

  • Seat Tilt Angle Range: 0° to 30°
  • Back Support Angle Range: 0° to 85°
  • Foot Support Angle Range: 0° to 90°

Electrical

  • Optional Electrical Outlet Rating: 115 VAC, 3 Amps
  • Electrical Ratings (standard models): 115 VAC, 10 Amps, 50/60 Hz
  • Electrical Ratings (rotation models): 115/230 VAC, 7.5/3.8 Amps, 50/60 Hz
  • Electrical Ratings (heated top models): 115 VAC, 7 Amps, 50/60 Hz

Contents

  • Stirrups: Standard
  • Paper Roll Holder: Holds 18″ × 3.5″ paper roll (45.7 × 8.9 cm)

Standards

  • Safety Standards: UL 60601-1; CAN/CSA C22.2 No. 601.1-M90
