Details
Portable, battery-powered x-ray generator ideal for mobile use
X-ray generator provides excellent imaging quality, accuracy, reproducibility, and long term stability in a portable, battery powered configuration. For more information on the Battery Powered Digital X-Ray available through DRE, contact an DRE representative today.
Features
- Convenient, battery-powered design is portable for field work.
- Built-in color touchscreen clearly displays x-ray settings and diagnostic information.
- Easy-to-use interface allows clinicians to easily select and change x-ray parameters.
- Comes standard with x-ray unit, battery pack, hand switch, and mobile stand.
- Rapid kV rising time minimizes unnecessary patient doses and creates superior image quality.
- Durable design with solid body.
- Optional — footswitch.
Specifications
General
- Max output power: 1.2 kW
- Battery charger input: 100V - 240V~
- Battery charger output: DC 29.4V
- MAs range: 0.4mAs - 32mAs, 20 steps
- Maximum kV deviation: ±3 %
- Maximum mAs deviation: ±5 %
- Display: 7 in LCD (1280 x 800)
- Weight: 23.4 lb
Hand Switch
- Two step x-ray exposure hand switch
- Working voltage (AC/DC): 125V/30V
- Working current (AC/DC): 1A/2A
Mobile Stand
- Arm angle: 0° ~ 150°
- Max arm vertical: 4.6 ft
- Maximum load capacity: 66.1 lb
- Wheel size: 50Ø, 0.9 in
- Weight (mobile stand): 25.6 lb
